Fan idBlocks 4042

idBlocks 4042 Fan: belt label applicator for uneven surfaces

idBlocks 4042 Fan is a belt label applicator for uneven surfaces, corner labels and products with difficult geometries. Its belt-based system applies labels while products move through the production line, helping manufacturers label packs that are not suited to a conventional fixed-position applicator.

The system can be configured for upper and lower corner labels, as well as selected side and rear positions. It is suitable for cartons, outer cases, industrial packaging and selected cylindrical containers, including paint tins, where label placement and adhesion require a more adaptable process.

Belt labelling for corners and irregular packaging

Apply labels while products move

The idBlocks 4042 Fan uses belts to accompany the product during the labelling process. This supports label application in motion and helps maintain a continuous automated workflow.

It is a practical option for production lines where products need to be labelled without stopping or manual handling.

Designed for difficult product geometries

Some packaging formats cannot be labelled effectively with a standard contact applicator. Uneven surfaces, corner applications, cylindrical packs and non-flat products can require a different approach.

The belt system helps position and apply the label on suitable irregular products, provided that the real pack, label material and adhesive are validated before installation.

Flexible label placement across the pack

Corner, side and rear label application

idBlocks 4042 Fan can be configured to apply labels on upper or lower corners, as well as on selected side and rear positions. This makes it suitable for applications where the label must remain visible, accessible or correctly positioned for logistics and traceability processes.

Pusher-assisted label contact

A pusher mechanism can be specified to help press the label onto the product surface after application. This is particularly useful for corner labels and suitable non-flat packs where consistent adhesion is important.

Print and apply variable data for traceability

When configured as part of a print-and-apply solution, idBlocks 4042 Fan can support real-time variable information on the label.

Typical label content includes:

  • Product references and descriptions.
  • Batch, lot and production data.
  • Best-before or use-by dates.
  • Barcodes, QR codes and Data Matrix codes.
  • Logistics and shipping information.
  • Text, logos and handling instructions.

This supports clearer product identification and traceability across packaging, dispatch and distribution operations.

Built around your production line

Label size and production output

The system supports label formats from 40 × 40 mm to 110 × 300 mm. It can operate at rates of up to 25 products per minute, depending on the product geometry, label size, application position and line conditions.

Options for line integration and control

idBlocks 4042 Fan can be specified with options to suit the installation, including:

  • Encoder synchronisation for variable conveyor speeds.
  • Barcode verification.
  • Light beacon for machine-status visibility.
  • External display for equipment parameters.
  • External control buttons for guarded or difficult-to-access installations.
  • Protective enclosure for dusty or humid environments.
  • Pusher configuration for corner and side label application.

Typical applications

idBlocks 4042 Fan can be assessed for applications including:

  • Corner labels on cartons and outer cases.
  • Uneven or non-flat packaging surfaces.
  • Cylindrical containers, such as paint tins.
  • Side and rear product identification.
  • Logistics, dispatch and traceability labels.
  • Food, beverage, construction, paint and consumer-goods packaging.

Configure the right labelling process

The best configuration depends on the product shape, label material, adhesive, label position, conveyor speed and available line space. Macsa id assesses the real product and production process before defining the appropriate belt, pusher, printer and verification setup.

Explore our print-and-apply labelling machines or discover Integra Vision code inspection software for code and barcode verification.

Contact the Macsa id UK team to discuss your labelling application.

Corner label application on a carton using idBlocks 4042 Fan
Belt labelling system for cylindrical paint tins
Belt-based label applicationThe belt system applies labels while products move through the production line, supporting a continuous automated process.
Corner and uneven-surface labellingDesigned for upper and lower corner labels, as well as suitable side and rear positions on uneven or difficult product surfaces.
Pusher-assisted label contactAn optional pusher helps secure the label onto suitable non-flat products, corners and irregular packaging formats.
Label formats from 40 × 40 mm to 110 × 300 mmThe system supports a versatile range of label sizes for product identification, logistics and traceability applications.
Outputs of up to 25 products per minuteSuitable for production lines that need reliable label placement at rates of up to 25 products per minute, depending on the application.
